With its robust chassis and reliable powertrain, the HOWO 6×4 Concrete Mixer Truck is suitable for a wide range of infrastructure and construction projects, including buildings, highways, bridges, tunnels, urban development, and commercial concrete delivery.
I. Basic Vehicle Specifications
| Item |
Specification |
| Vehicle Model |
HOWO 8×4 Concrete Mixer Truck |
| Drive Type |
8×4 (four axles, 10 tires) |
| Mixing Drum Capacity |
12 m³ (8 / 9 / 10 m³ optional) |
| Gross Vehicle Weight (GVW) |
25,000 kg |
| Curb Weight |
Approx. 13,000 kg |
| Rated Payload |
Approx. 12,000 kg |
| Wheelbase |
3,600 + 1,400 mm (other options available) |
| Max Speed |
80–90 km/h |
| Electrical System |
24V, 165Ah battery, English-labeled instrument cluster |
| Color |
Engineering Yellow / White (customizable) |
II. Powertrain
| Item |
Specification |
| Engine |
Weichai / SINOTRUK WD615.47, inline 6-cylinder diesel, Euro II emission (mechanical injection pump) |
| Horsepower |
371 HP |
| Displacement |
9.726 L |
| Transmission |
SINOTRUK HW19710 10-speed manual (with PTO) |
| Clutch |
Φ430mm dry-type diaphragm spring clutch |
| Fuel Tank |
300L aluminum alloy fuel tank |
| Air Filter |
Oil-bath heavy-duty air filter (suitable for dusty environments in Africa) |
| Braking System |
Exhaust brake + drum brake; ABS optional |
III. Chassis, Axles & Suspension
| Item |
Specification |
| Front Axle |
HF9 9-ton steering front axle |
| Rear Axle |
HC16 16-ton double reduction rear axles (tandem), ratio 5.73 |
| Chassis Frame |
320 × 90 × 8 mm double-layer reinforced frame |
| Suspension |
Front & rear multi-leaf steel springs, reinforced U-bolts |
| Steering |
Germany ZF8098 hydraulic power steering |
| Tires |
12.00R20 steel radial tires |
IV. Cab
| Item |
Specification |
| Basic Configuration |
HOWO HW79 medium-roof cab, four-point suspension |
| Comfort Features |
Factory heating & cooling A/C, hydraulic seat, manual cab tilt |
| Adapted Configuration |
English instrument cluster, HOWO English logo, metal front bumper with crash protection |
V. Mixing System (Standard)
| Item |
Specification |
| Drum Material |
Q345B high-strength structural steel + NM400 wear-resistant lining, double-helix mixing blades |
| Drum Inclination Angle |
12°–13° |
| Drum Rotation Speed |
0–14 r/min (stepless speed regulation) |
| Charging / Discharging Rate |
Charging ≥ 3.0 m³/min; Discharging ≥ 2.1 m³/min |
| Reducer |
Italy Bonfiglioli imported reducer |
| Hydraulic System |
USA EATON hydraulic motor + variable displacement piston pump |
| Water Supply System |
Pneumatic water tank, 400–440L |
| Auxiliary Equipment |
Discharge chute, ladder, operating platform, support rollers |
VI. Standard & Optional Equipment
| Item |
Content |
| Standard Equipment |
Tool kit, English labels, oil-bath air filter, exhaust brake, complete mixing hydraulic system, operating platform & ladder |
| Premium Optional Equipment |
1. Axle differential lock (original imported); 2. ABS anti-lock braking; 3. 400L enlarged fuel tank; 4. Weighing hydraulic system (anti-overfill); 5. Side protection guards |
Key Features
- Reliable 6×4 Chassis: The 6×4 drive configuration provides strong traction and stable driving performance on construction sites and different road conditions.
- Efficient Mixing System: The concrete mixer drum is designed to maintain uniform concrete mixing during transportation and help ensure consistent material quality.
- Heavy-Duty Construction: The robust chassis and vehicle structure are suitable for demanding working environments and frequent transportation operations.
- Efficient Concrete Discharge: The mixer system allows practical loading, mixing, transportation, and discharge of concrete at construction sites.
- Wide Application Range: Suitable for ready-mix concrete transportation and various infrastructure and building construction projects.
- Easy Maintenance: The practical vehicle structure helps simplify routine inspection and maintenance during long-term operation.
Applications
The HOWO 6×4 Mixer Truck is widely used for transporting ready-mixed concrete from concrete batching plants to construction sites. Typical applications include:
- Building construction
- Highway and road construction
- Bridge and tunnel projects
- Urban infrastructure
- Commercial concrete delivery
- Large-scale construction projects
HOWO 6×4 Concrete Mixer Truck for Construction
The HOWO 6×4 Mixer Truck provides a practical solution for contractors, ready-mix concrete suppliers, construction companies, and vehicle distributors. Its combination of a heavy-duty 6×4 chassis and efficient concrete mixing system makes it suitable for continuous concrete transportation in demanding working environments.
For customers looking for a HOWO 6×4 Concrete Mixer Truck for sale, this model offers a reliable option for concrete transportation and construction applications.
